Jepson 72223060 Drytech HM Circular Saw Blade LBS Impact-Resistant Ø 230 x 25.4 x 1.4 mm 60T for Thin-Walled Steel
The Drytech LBS HM saw blade Ø 230 mm with 60 teeth has been specially developed for fast and accurate cutting of thin-walled steel materials. Thanks to the shock-resistant LBS (Laser Beam Saw) design and the ultra-thin kerf, this blade delivers fast, clean cuts with less material loss and reduced strain on the machine. Ideal for cutting steel gratings, structural steel, cable trays, pipes, trapezoidal sheets, and other thin-walled metal structures. Dry Cutting technology eliminates the need for coolants and lubricants, ensuring an efficient and environmentally friendly working method.
Special features
- Specially developed for thin-walled steel
- Shock-resistant LBS design reduces the risk of tooth breakage
- Ideal for steel gratings, gratings, trapezoidal sheets, profiles, cable ducts, and pipes
- Ultra-thin kerf of just 1.4 mm for minimal material loss
- Faster cutting thanks to lower resistance during cutting
- Dry Cutting technology eliminates the need for coolants and lubricants
- Environmentally friendly and clean cutting process
- Lower energy consumption due to the thin blade construction
- High cutting quality with minimal burr formation
- Reduced vibration for more comfortable working
- Suitable for professional use in metalworking
- Carbide teeth for long service life and consistent performance
Technical data
- Blade diameter: 230 mm
- Bore: 25.4 mm
- Cut width (kerf): 1.4 mm
- Number of teeth: 60
- Maximum speed: 3,000 rpm
- Model: LBS (Laser Beam Saw), shock-resistant
- Tooth material: Carbide (HM)
- Application: Thin-walled steel
Scope of delivery
- 1x Drytech HM saw blade LBS impact-resistant Ø 230 mm / 60T for thin-walled steel (item no. 72223060)
